NVIDIA Jetson AGX Xavier Developer Kit

NVIDIA
SKU:
812674022369
|
UPC:
812674022369

Dear Customer, due to global shortage, NVIDIA is restricting the sale of these developer kits to most critical sectors of the economy. Please contact us if you would like to make a purchase. Thank you

NVIDIA: Up to 1 year(s) warranty from date of purchase. Please contact us to speak with a product specialist if you would like to deploy this solution for client projects or bulk purchase enquiries.
Current Stock:

The NVIDIA Jetson AGX Xavier Developer Kit is the latest addition to the Jetson platform. It’s an AI computer for autonomous machines, delivering the performance of a GPU workstation in an embedded module under 30W. Jetson AGX Xavier is designed for robots, drones and other autonomous machines.

With the NVIDIA Jetson AGX Xavier developer kit, you can easily create and deploy end-to-end AI robotics applications for manufacturing, delivery, retail, agriculture, and more. Supported by NVIDIA JetPack and DeepStream SDKs, as well as CUDA®, cuDNN, and TensorRT software libraries, the kit provides all the tools you need to get started right away. And because it’s powered by the new NVIDIA Xavier processor, you now have more than 20X the performance and 10X the energy efficiency of its predecessor, the NVIDIA Jetson TX2.

Technical Specifications

  • GPU 512-core Volta GPU with Tensor Cores
  • CPU 8-core ARM v8.2 64-bit CPU, 8MB L2 + 4MB L3
  • Memory 32GB 256-Bit LPDDR4x | 137GB/s
  • Storage 32GB eMMC 5.1
  • DL Accelerator (2x) NVDLA Engines
  • Vision Accelerator 7-way VLIW Vision Processor
  • Encoder/Decoder (2x) 4Kp60 | HEVC/(2x) 4Kp60 | 12-Bit Support
  • Size 105 mm x 105 mm x 65 mm
  • Deployment Module (Jetson AGX Xavier)
  • PCIe X16 x8 PCIe Gen4/x8 SLVS-EC
  • RJ45 Gigabit Ethernet
  • USB-C 2x USB 3.1, DP (Optional), PD (Optional) Close-System Debug and Flashing Support on 1 Port
  • Camera Connector (16x) CSI-2 Lanes
  • M.2 Key M NVMe
  • M.2 Key E PCIe x1 + USB 2.0 + UART (for Wi-Fi/LTE) / I2S / PCM
  • 40-Pin Header UART + SPI + CAN + I2C + I2S + DMIC + GPIOs
  • HD Audio Header High-Definition Audio
  • eSATAp + USB3.0 Type A SATA Through PCIe x1 Bridge (PD + Data for 2.5-inch SATA) + USB 3.0
  • HDMI Type A HDMI 2.0
  • uSD/UFS Card Socket SD/UFS
